Home » Lancer Tower 302 Island Base Stainless Steel Beverage Dispenser | 2 LEV® Push Button Valves, Key Lock, 24V
Free shippingLancer Tower 302 Island Base Stainless Steel Beverage Dispenser | 2 LEV® Push Button Valves, Key Lock, 24V
Lancer · Authorized Dealer

Lancer Tower 302 Island Base Stainless Steel Beverage Dispenser | 2 LEV® Push Button Valves, Key Lock, 24V

SKU: 85-3132-101
$493.51$599.99Save $106.48

Not sure if this is the right one for your build? Take the 30-second picker ↓

⚡
Same-day shipOrder by 2pm CT
📞
Live techsReal install help: 888-964-4239
🛡️
Factory warrantyLancer 1-yr parts & labor
🔁
30-day returnsIf new and uninstalled
Confirm your fit · 30 seconds

Is the 302 Push-Button the right dispenser for your build?

The PB variant uses crew-operated push-button valves — different from the LEV self-serve lever sister. Answer 3 questions and we'll confirm this one or route you to the right sibling.

1. What's the situation?

2. Who pulls the drink — customer or staff?

3. How many flavors do you need on tap?

4. About how many drinks per day at peak?

2. What dispenser are you replacing?

3. Why are you replacing it?

· Or call our techs at 888-964-4239
Don't get caught short

Build the complete 2-valve install in one click

The 302 PB is the tower head — sized for a counter cold plate or ice well. To pour you also need a CO₂ supply, regulator, carbonator, BIB rack, syrup pumps, water filter, backflow preventer, and tubing. We've pre-specced all of it. Uncheck what you already have.

Complete Lancer 302 PB install bundle (2-valve)

Required + recommended components per Lancer's install guide. The 302 chills via external cold plate or ice bath — your existing bar setup typically has this.

2-valve preset
    $0 0 items selected
    Already own a Lancer?

    Skip the rebuild — find the part you need

    Most Lancer service jobs are one or two parts, not a whole new dispenser. Below are our top-selling Lancer replacement parts — or jump straight to the full catalog.

    Lancer LPV 3.0 Versapour Selfserve Lever Valve | 19-73311-L

    Lancer LPV 3.0 Versapour Selfserve Lever Valve | 19-73311-L

    $89.99 $99.99
    Lancer Syrup Separator - For LEV/GMV 3.0 oz Soda Valves

    Lancer Syrup Separator - For LEV/GMV 3.0 oz Soda Valves

    $10.87 $20.05
    Lancer Diffuser One Piece LEV - 05-3261

    Lancer Diffuser One Piece LEV - 05-3261

    $3.99 $4.73
    Lancer Block Mounting Assembly for GMV/Versa-Pour - 82-0274-SP

    Lancer Block Mounting Assembly for GMV/Versa-Pour - 82-0274-SP

    $10.24

    Lancer Nozzle 2 Shot GMV 3.0 - 05-1463/03

    Lancer Nozzle 2 Shot GMV 3.0 - 05-1463/03

    $3.35 $6.33
    Lancer Micro Switch Replacement for LEV 3.0 & 4.5 oz. Soda Valves - Models 100 & 145

    Lancer Micro Switch Replacement for LEV 3.0 & 4.5 oz. Soda Valves - Models 100 & 145

    $1.84 $2.30
    Lancer 120V Agitator Motor Assembly, 5/3 Gal - 91-4020-SP

    Lancer 120V Agitator Motor Assembly, 5/3 Gal - 91-4020-SP

    $89.99

    Lancer LPV 3.0 Versapour Self-Serve Valve | 19-73311-MB - 19-73311-MB

    Lancer LPV 3.0 Versapour Self-Serve Valve | 19-73311-MB - 19-73311-MB

    $165.28 $195.91
    Lancer 3.0 oz/sec LEV 3.0 Self-Serve Lever Valve & Block - 19-0120/03

    Lancer 3.0 oz/sec LEV 3.0 Self-Serve Lever Valve & Block - 19-0120/03

    $96.45

    Lancer LEV Self-Serve Lever Valve, No Cover - 19-0359/03

    Lancer LEV Self-Serve Lever Valve, No Cover - 19-0359/03

    $92.87

    Lancer 500 Series 2-Circuit Line Chiller - 85-0552A

    Lancer 500 Series 2-Circuit Line Chiller - 85-0552A

    $1,599.90 $1,999.99
    Lancer LEV 3.0 Series Service Valve - Genuine OEM Replacement

    Lancer LEV 3.0 Series Service Valve - Genuine OEM Replacement

    $110.82

    View all Lancer replacement parts →
    Compare the Lancer 30x family

    Same chassis, different valve types & flavor counts

    All four are tower-style island base dispensers built on the same 24V LEV platform. Pick by valve type (self-serve vs push-button) and flavor count.

    Model
    This product
    302 Push-Button
    85-3132-101
    $493.51
    302 Self-Serve
    2-Valve
    $469.30
    305 Island Base
    5-Valve
    $1,729.47
    306 Island Base
    6-Valve
    $1,923.55
    Valve count2 LEV2 LEV5 LEV6 LEV
    Valve typePush-buttonSelf-serve leverSelf-serve leverSelf-serve lever
    Best forBars, drive-thrus, crew-servedCustomer fountain stationsMid-flavor menusFull-flavor menus
    Power24V (transformer)24V24V24V
    CoolingExternal (cold plate / ice bath)ExternalExternalExternal
    Key lock✓✓✓✓
    BuildStainless steelStainless steelStainless steelStainless steel
    You're hereView →View →View →
    Inside the 302 Push-Button

    Five things you connect, no internal cooling

    The 302 PB is a tower-style dispenser — sits on a counter cold plate or in an ice bath. Same chassis as the self-serve sister; the only difference is the actuator (push-button instead of LEV lever).

    KEY LOCK brand panel 2 push-button valves drip tray EXTERNAL COLD PLATE / ICE BATH 1 2 3 4 5
    • 1
      Water in1/4" line at 40+ PSI flowing. Filtered through the BEV135 → carbonator → tower.
    • 2
      CO₂ inFrom the 20 lb tank → primary regulator → carbonator → tower at 70–80 PSIG.
    • 3
      Syrup in × 2One Bevlex line per BIB, pulled by a Flojet pump at 55–65 PSI. Two lines = two valves.
    • 4
      Cold plate or ice bath (external)The 302 has no internal cooling — it relies on the bar's existing counter cold plate or a flooded ice well. Lines pre-chill before they reach the valves.
    • 5
      Power24V via the included transformer (plugs into a standard 115V receptacle).

    Lancer Tower 300 Series Spec Sheet

    Full Lancer reference covering 302, 305, and 306 tower variants — exact dimensions, electrical, water + CO₂ specs, valve options (PDF).

    Download →
    Before your installer shows up

    Pre-install checklist

    Seven things to confirm before the truck arrives. Saves a return visit.

    ✓
    External cold plate or ice wellThe 302 has no internal cooling. Most bar wells already have one — confirm yours does, or budget for a counter cold plate.
    ✓
    115V outlet within 6 ftFor the 24V transformer that ships with the tower. Standard residential receptacle is fine.
    ✓
    Cold water line, 1/4" min40+ PSI flowing. If under 40, add the booster pump from the bundle.
    ✓
    Floor drain with air gap3/8" line. Code requires the air gap — don't hard-pipe.
    ✓
    CO₂ supply staged20 lb tank fits under most counters. Fill at a local welding/beverage gas supplier.
    ✓
    Tower mount footprint~9-1/2" wide × ~13" deep on the counter. Plumbing comes up through the counter to the tower base.
    ✓
    BIB shelf / under-counter spaceOne BIB rack (~24" × 12") holds the 2 syrup boxes for this tower.
    Common questions

    What buyers ask before they pull the trigger

    Push-button is the right call when a crew member operates the dispenser — bartenders, drive-thru staff, deli counter operators. The button is press-and-release: no cup contact, no leaning required, and easier on operators pouring 100+ drinks per shift. Self-serve (LEV) is the right call when customers fill their own cups at a fountain station. Same chassis, same plumbing, same key lock — the only difference is the actuator.
    No — and this is the most common surprise. The 302 is a tower head only. It mounts above (or in) an external cold plate or ice bath. Most bar wells and counter-mount stations already have a cold plate built in. If yours doesn't, budget for a separate counter cold plate. Call our techs and we'll spec one to fit your setup.
    No. The 302 is the tower only. You also need a carbonator (we ship the McCann's Big Mac), CO₂ supply, regulator, syrup pumps, BIB racks, and tubing. The bundle above pre-specs all of it from Lancer's install guide.
    No special wiring. The 302 ships with a 24V transformer that plugs into a standard 115V receptacle. The 24V is just what the LEV solenoid valves run on internally. Same household outlet you'd use for any small appliance.
    No — the 302 chassis is hard-built for 2 valves. If you think you'll grow past 2 flavors within a year or two, step up to the 305 (5-valve) or 306 (6-valve) instead. Same tower platform, same install pattern, just more capacity. We can quote both side by side.
    Daily: wipe nozzles and the drip tray, sanitize valve faces. Weekly: chemical syrup-line cleaning per BIB. Quarterly: change the BEV135 water filter and inspect the backflow preventer. We sell the cleaning kits — call our techs if you want a maintenance bundle priced out.
    Lancer factory warranty is 1 year parts and labor on the tower. We stock the 302 — most orders ship same-day if placed before 2pm CT, ground transit 3–5 days to most US zips. International freight available, call for a quote.

    Still unsure? Call the techs.

    You're spending $3K+ on a 10-year piece of equipment. A 5-minute call with someone who's installed 200 of these is free, and almost always cheaper than the wrong order.

    888-964-4239 Mon–Fri 8:30am–5pm CT
