Lancer 115V 1/15 HP High-Torque PSC Agitator Motor - 91-0165/03-SP
Lancer 115V 1/15 HP High-Torque PSC Agitator Motor - 91-0165/03-SP
- Restores cooling water circulation.
- Prevents ice bank 'bridging' freeze-ups.
- Official Lancer OEM high-torque motor.
- SKU: 91-0165/03-SP
Request a quote
Need a custom build, freight order, or just want pricing in writing before you order? Quotes back within 24 hours.
The Lancer Motor AC PSC CS 12.5 MFD BB 115/60 1A 1/15 HP is the electrical agitating drive unit responsible for maintaining the ice bank's water circulation. Using a high-torque Permanent Split Capacitor (PSC) design, it drives the propeller that moves water across the evaporator coils, ensuring the ice bank acts as an efficient cooling battery for the product lines.
Problem Solved: Restores circulation to prevent ice bank 'bridging'—where ice freezes solid around the product coils—ensuring even cooling across all beverage circuits. Fixes 'warm soda' calls where the compressor is running but the water bath is stagnant.
Symptoms of Failure: A loud humming noise from the unit top without rotation, warm drinks at the tap despite the compressor running, or the unit tripping the circuit breaker whenever the refrigeration cycle starts.
- Voltage: 115V / 60Hz
- Power/Current: 1/15 HP / 1A
- Capacitor Req: 12.5 MFD
- Manufacturer: Lancer
