Honeywell Home HVAC Zoning Control 24V YTH6320R1023/U
Honeywell Home HVAC Zoning Control 24V YTH6320R1023/U
- HVAC Zoning Control 24V
- 24V operation
- Genuine Honeywell Home part YTH6320R1023/U
Request a quote
Need a custom build, freight order, or just want pricing in writing before you order? Quotes back within 24 hours.
The Honeywell Home YTH6320R1023/U is a hvac zoning control for zoned heating and cooling control. Honeywell - YTH6320R1023/U - Wireless Zoning Adapter Kit, Programmable
Specifications
| Voltage | 24 VAC |
| Heat Pump Compatible | Yes |
| Country of Origin | MEX |
| 750mV Compatible | No |
| Accuracy | +/- 1°F |
| Ambient Temperature Range | Thermostat at 32°F to 120°F (0°C to 48.89°C), Wireless Adapter at -40°F to 165°F (-40°C to 73.89°C) |
| Auto Changeover | No |
| Backlit | Yes |
| Batteries Included | No |
| Battery Backup | Yes |
| Built In Wi-Fi | No |
| Change/Check Reminders | No |
| Daylight Savings Time Ready | No |
| Digital | Yes |
| Digital-Non Programmable | No |
| Digital-Programmable | Yes |
| Display | Yes |
| Displays Outdoor Temperature | Yes |
| Display Options | Backlit, Digital |
| Dual Transformer Compatible | No |
| Electrical Connection Type | Screw terminals |
| Electrical Rating | 20-30 VAC |
| Fan Switching | Yes |
| Humidification | No |
| Indoor Remote Sensor | No |
| Language | English; French; Spanish |
| Low Battery Indicator | Yes |
| Manual | Yes |
| Operating Temperature Range | Thermostat at 32°F to 120°F (0°C to 48.9°C); Wireless Adapter at -40°F to 165°F (-40°C to 73.9°C) |
| Power Method | Battery; Hardwired |
| Programmable Fan | No |
| Removable Interface | No |
| System Switching | Yes |
| Temperature Range | Heat: 40°F to 90°F (4.44°C to 32.22°C), Cool: 50°F to 99°F (10°C to 37.22°C) |
| Terminal Designations | C, R, Rc, Rh, W-O/B, W2-Aux/E, Y, Y2, G, L, RAS |
| Touchscreen | No |
| Vacation Mode | No |
| Works with Google Assistant | No |
| Works with Rheem EcoNet | No |
| Mounting Type | Mount Wireless Adapter on wall near HVAC equipment or on the duct. Mount thermostat horizontally. |
| Stages Cooling | 2 |
| Stages Heating | 2 |
Honeywell Home publishes the figures in the table above for this part number. Nothing here is inferred — if a value you need is not listed, it was not published by the manufacturer, and we would rather tell you that than guess.
For the installer: confirm nominal size and connection type against the existing run before ordering. Sizes in this category are quoted by the convention the manufacturer uses for the product family, which is not always the same as nominal pipe size.
