Ranco® Dual Pressure Control - O12-4834
Ranco® Dual Pressure Control - O12-4834
- Height (in.): 3
- Width (in.): 6
- Genuine Ranco® part O12-4834
Request a quote
Need a custom build, freight order, or just want pricing in writing before you order? Quotes back within 24 hours.
Ranco® O12-4834 is a Dual Pressure Control. Matching the original part number is the surest way to keep the assembly working as designed.
It also cross-references 1 manufacturer part number. Check the number on the part you are replacing, or your unit's model number, against the lists below before ordering. The specifications below are the published figures for this exact part number.
Supplied as a single replacement unit.
Low Pressure Range = (10") To 100 Psig, Differential = 10-40 Psig High Pressure Range = 150-450 Psig, Differential = Fixed @ 70 PSI Drop Reset, High = Automatic Or Manual Cap Connections = 48" With Flare Nut Full Load Amps = 120/240VAC, 24A Locked Rotor Amps = 120/240VAC, 144A Pilot Duty Volt Amps = 120/240VAC, 720VA.
Specifications
| Height (in) | 3 |
| Width (in) | 6 |
Cross-reference
- Ranco: O12-4834
Ordering by part number is the most reliable way to get the right part. If you are matching an existing component, compare the values in the table rather than the description.
