Manitowoc Ice IYT0420A/D420 460 lb Indigo NXT™ Half Cube Ice Machine w/ Bin - 383 lb Storage, Air…
Manitowoc Ice IYT0420A/D420 460 lb Indigo NXT™ Half Cube Ice Machine w/ Bin - 383 lb Storage, Air…
Request a quote
Need a custom build, freight order, or just want pricing in writing before you order? Quotes back within 24 hours.
The Manitowoc Ice IYT-0420A-161/D-420 Indigo NXT™ ice maker with bin can provide a 460-pound maximum daily output. Ice thickness is measured by an acoustical sensing probe, ensuring each cycle is uniform. Through the control system, preventive maintenance provides users with diagnostic feedback. If there is an issue in the foodzone, the operator can easily access the area through the swing-out front door. This access design also simplifies cleanup, and some of the parts are removable and made with AlphaSan® antimicrobial.
A 383-pound-capacity bin is included with the Manitowoc Ice IYT-0420A-161/D-420 ice maker. Scooping ice is simple since a 5.3-pound-capacity scoop comes with the unit; its retaining lip holds ice in the scoop. The knuckle and thumb guard does not allow hands to come in contact with the ice, preventing cross contamination. When the operator scoops ice, the self-latching door stays open. Users can easily reach the bottom of the bin since the door is set at a 53-degree angle. Insulated with foam, the door resists condensation buildup.
Ice Machine
- Part of the Indigo NXT series
- 460 lb. maximum daily ice production
- 375 lb. AHRI-certified daily ice production
- Produces half cube ice
- Ice size: 0.375 in. x 1.125 in. x 0.875 in.
- easyTouch® display system
- Ice production programmable by time or volume
- Acoustical sensing probe ensures consistent ice thickness
- 24-hour preventive maintenance and diagnostic feedback
- Hinged, swing-out foodzone door for easy access
- Removable components include distribution tube, curtain, water probe, water pump, and water trough
- AlphaSan antimicrobial agent on key components slows bacteria growth
- DuraTech™ exterior resists corrosion, fingerprints, and smudges
- Refrigerant: R410A
- Required ambient air temperature: 40–110°F
- Required incoming water temperature: 40–90°F
- Cooling Capacity: 3,800–6,000 BTU
Ice Storage Bin
- Application Capacity: 383 lbs.
- AHRI-Certified Capacity: 310 lbs.
- Ice Scoop: 5.3-lb. ergonomic scoop included
- Scoop Safety: Integrated scoop guard keeps hands separate from ice
- Scoop Storage: Molded-in retaining lip
- Door Access: Side grips allow opening from any angle
- Door Operation: Self-latching door stays open during scooping
- Door Angle: 53 degrees for access to the bottom of the bin
- Insulation: Foam-insulated door prevents condensation buildup
- Interior Liner: Arctic blue polyurethane
Dimensions & Utilities
- Ice Machine: 22 in. W x 34 in. D x 71.5 in. H
- Storage Bin: 22 in. W x 34 in. D x 50 in. H
- Electrical Load: 11.3 A, 5.4 kW
- Electrical Requirements: 115 V / 60 Hz / 1 ph
| Manufacturer | Manitowoc Ice |
| 24 Hr. Production (lb) | 460 |
| Access | Lift Up Door |
| Bin Capacity (lb) | 383 |
| Compressor Type | Air Cooled |
| Depth (in) | 34 |
| Height (in) | 71.5 |
| Hertz | 60 |
| Ice Type | Half Cube |
| Phase | 1 |
| Product | Ice Machines with Bins |
| Product Type | Ice Makers & Bins |
| Rating | Best |
| Refrigerant | R410A |
| Series | Indigo NXT™ |
| Suggested Use | Commercial |
| Voltage | 115 |
| Warranty | Machine: 3-year Parts & Labor, 5-year Compressor Parts; Dispenser: 3-year Parts & Labor |
| Water Inlet (in) | 0.38 |
| Width (in) | 22 |
| Weight | 244.00 |
