Fasson Foil Tape 3" x 180' 2 Mil Aluminum Foil 56477 03000180
Fasson Foil Tape 3" x 180' 2 Mil Aluminum Foil 56477 03000180
- 3" x 180' 2 foil tape
- 2 Mil Aluminum Foil construction
- Rated to 400°F (204.44°C)
- Genuine Fasson part 56477 03000180
Request a quote
Need a custom build, freight order, or just want pricing in writing before you order? Quotes back within 24 hours.
The Fasson 56477 03000180 is a 3" x 180' foil tape for duct sealing and joint closure. Avery Dennison - 56477 03000180 - Fasson 0800 3.0" x 60 Yards UL 181 A-P / B-FX Aluminum Foil Tape
Specifications
| Size | 3" x 180' |
| Type | Foil |
| Composition | 2 Mil Aluminum Foil |
| Roll Length | 180 Feet |
| Roll Width | 3" |
| Thickness | 6.90 mil |
| Maximum Temperature | 400°F (204.44°C) |
| Performance Temperature | 350°F (176.67°C) |
| Application Temperature | >50°F (>10°C) |
| Adhesion Strength | 5 lbs/in |
| Tensile Strength | 25 lbf/in minimum |
| UV Resistant | Yes |
| Shelf Life | One year when stored at 64-72ºF (18-22ºC) / 30-70% relative humidity, out of direct sunlight and in original packaging |
| Country of Origin | USA |
| Storage Temperature | 64°F to 72°F (17.78°C to 22.22°C) |
Fasson publishes the figures in the table above for this part number. Nothing here is inferred — if a value you need is not listed, it was not published by the manufacturer, and we would rather tell you that than guess.
For the installer: confirm nominal size and connection type against the existing run before ordering. Sizes in this category are quoted by the convention the manufacturer uses for the product family, which is not always the same as nominal pipe size.
