T&S Big-Flow Pre-Rinse Unit, 8" Wall Mount, 12" Add-On Faucet, B-0107-C Spray Valve, Inlet Kit
Regular price
$813.72
GET PRO PRICING
Get lower prices, 30-Day Terms & 3% Back.
Create a Free HowdyPro account
Quick Overview
- 0.65 GPM low flow spray valve
- 12" Big-Flo plain end swing nozzle
- 18" riser
- 3/4" NPT female eccentric inlets with 2" flanges with 3/4" NPT female inlet elbows & 3/4" NPT male inlets
- 4-arm handles with color coded indexes
- 44" flexible stainless steel hose with heat resistant gray handle and hold down ring
- 6" adjustable wall bracket
- 8" wall mount Big-Flo mixing faucet with polished chrome plated brass body
- Adjustable centers from 7 3/4" to 8 1/4"
- Big-Flo compression spindles
- Check valves in body to prevent cross flow of water
- EasyInstall add-on Big-Flo faucet with polished chrome plated brass body
- Material: Polished chrome plated brass body, add-on faucet body, tubular spout, riser & spray valve body, stainless steel hose, and chrome plated metal handles
Product Description
⌄8" wall mount large flow mixing faucet with polished chrome plated brass body, add-on faucet with compression spindle and 4-arm handle, 12" plain end swing nozzle, 18" riser, 44" flexible stainless steel hosewith heat resistant handle, 0.65 GPM low flow spray valve, compression spindles, 4-arm handles, 3/4" male inlets, check valves in body, spray valve holder,6" adjustable wall bracket and overhead spring. Certified to ASME A112.18.1/CSA B125.1, NSF 61-Section 9 and NSF 372. 2019 DOE PRSV - Class I compliant.
- Body: 8 in Centers (203.2 mm)
- Body Mount: Wall
- Cartridge-Spindle: Compression
- Feature: 6 in Wall Bracket (152.4 mm)
- Feature: Big-Flo
- Feature: Check Valve
- Handle: 4-Arm (Cross)
- Inlet: 3/4 in NPT Female
- Inlet: Adjustable Centers
- Inlet: Inlet Elbow
- Material: Brass Construction
- Nozzle: 12 in (304.8 mm)
- Nozzle: Add-On Nozzle
- Nozzle: Nozzle
- Nozzle: Swivel
- Nozzle Flow: 29.5 GPM (111.66 L/min)
- Nozzle Outlet Type: Plain End
- Pressure Max: 125 psi (8.62 bar)
- Pressure Min: 20 psi (1.38 bar)
- Spray Valve: B-0107-C (0.65 GPM) (2.46 L/min)
- Spray Valve Flow: 0.65 GPM (2.46 L/min)
- Temperature Max: 140 F (60℃)
- Temperature Min: 40 F (4.44℃)
